Flat Cable Assembly with IDC Solutions: time tested reliability and convenience in various use cases


Various IDC connectors available for fast and reliable assembly of Flat cables. Different interfaces and pin counts to serve specific applications whiile devices and many equipment used various protocols which involves high density connections requiring fast and reliable terminations.

AUK is a Flat Cable Assembly manufacturer and supplier founded in Taiwan for nearly 40 years, providing high-quality products, and as one of competitive Flat Cable Assembly suppliers worldwide as well as OEM ODM precision manufacturing services.

AUK delivers off-the-shelf and Customized Flat cable solutions, various connectors available accommodating Flat cable using IDC terminations. Pin-out available in 4 to 64 pins, as a socket or plug while also available in connectors like D-sub, DIN 41612 and MIM series. It delivers fast assembly process and reliability especially in demanding applications such as high bending conditions, low profile and harsh environment.


  • Various Connectors with IDC

    IDC is a style of terminating cables to connectors by inserting the wires into the contact blades and pressing it to cut through the insulation and make contact to the conductor. From D-sub, DIN 41612, MIM series or Socket, Plug, as Headers and with Ejector, these are all available to choose from.
  • Fast and Quick Assembly

    By pressing on an IDC connector, the inserted Flat cable can be easily connected. This is applicable for  connectors with numerous wire connections such as up to 64 Pins. The IDC connector must match corresponding flat cables to effectively establish connection.
  • Customized Strain & Relief

    SR or strain & relief solutions are available to add support to the flat cable to make sure it will be robust enough for multiple bending and other external pulling force that can be present during actual applications.
  • Numerous Circuit options

    Various Pin-out and contacts arrangement are available, ranging from 4Pins up to 64Pins depending on the Connector series. For example D-sub are available with 9, 15, 25 and 37 pins, while DIN41612 are with 32 and 64 pin counts, MIM series have 4 to 20 pins and the rest are available with 6 to 64 pins.
  • Hybrid Customized Solutions

    Cable assemblies are configured end to end, prepared with both ends having the same connector or with combination to other connector types or wire harness.These depends on the type of modules or systems that are being integrated to perform specific functions in a system.
  • Broad Applications and Services

    The continuous development of communication technology from Automotive, Industrial Automation and Network communications, provide uses for the Flat Cable assembly and is implemented by Connectors with IDC termination.
