RJ45 from 1Gbps to 10Gbps: network connectivity now and beyond


This de facto connector for Ethernet networking communication system having 8P8C, is a universally-recognized interface and it enables backward compatibility and interoperability to many applications. Other forms are RJ10(4P4C), RJ11(6P4C) up to RJ48(10P10C) used on telephones, ADSL and data communication. RJ45 supports Gigabit speed of 2.5Gbps, 5Gbps and up to 10Gbps vital to Home networks, Smart City, Transportation and IIOT.

AUK's broad modular jack options with various features such as Top or Side Entries, LED indicators, full Shielding with grounding, Ganged or stacked types, equipped with Transformers (Magnetics) and even customized (OEM/ ODM) solutions provides immediate configuration for any design in. While Industrial grade designs such as having IP65~IP67 rated waterproof protection can be used in a wide range of IOT applications like Outdoor Access points and are equipped with ingress protection to harsh environment exposure.


  • Low profile height solutions

    From 11mm Low Profile height on PCB surfacedown to 6mm using the Mid-mount type, halfway PCB mounted are used for thin device contour. These are extreme miniaturization of the RJ45 connector, intended to support designers achieve innovative solutions in small-form-factor.
  • High Performance with Transformer

    Transformer (Magnetics) either integrated or discrete configuration are used for isolation from harmful electric surges, it also supports the signal transmission for high speed data transfers ranging from 100Mbps, 1Gbps, 2.5Gbps, 5Gbps and up to 10Gbps as per IEEE standard.
  • Full Shielding/ Grounding Protection

    Protection against Interference and Noise are achieved with Shielding and Grounding. While the Panel ground (Spring) to connect to the device enclosure with single, dual or using all of its sides are used to make contact to the panel side.
  • Reliable LED Indicators

    LED indicators helps identify connection status within the network area. Available in colors such as Green, Yellow, Red, Orange, Beige, Amber, Bi-color options and other color preferences, while upper or lower position are selected in front of the Jack for direct visibility.
  • Multiple Port Configuration

    Many devices connects to the network, thus, multiple ports are used to support such dense connected lines. Arranged in Single or Dual rows, with number of ports reaching up to 8ports per row, while optional other features such as Full shielding, LED indicators and Transformers are also available integrated features.
  • IPX7 Rating Waterproof Protection

    Communication systems are now found in many places, dealing with environmental condition requiring rugged solution to enable devices to perform effectively even in harsh environment. Thus IPX7 Waterproof rated RJ45 connectors are designed with carefully selected materials, seals and potting to ensure that no water can get into the enclosure thta can damage it.

EXPLORE OUR SOLUTIONS

  • 5G Networking & Data Center
  • Personal computing device
  • Point of Sale Payment Terminals
  • Industry 4.0
