RF cable solutions, to fit the radio frequency market.
RF Cable Assembly plays a pivotal role in the connectivity market in nowadays.
Along with the improvement of telecommunication technology, the application for RF connector and cable has
expanded rapidly. The development of Internet of Things (IOT) and 5G has now brought more opportunities for the
Interconnect and Wireless products.
AUK’s various RF or Coaxial connectors, includes SMA, SMB, SMC, MCX, MMCX, BNC, TNC, Micro coaxial connector(MHF/ GSC) and others. There are actually many types of RF connectors; in the industrial and consumer market, the SMA, MMCX, BNC and Micro coaxial connector(MHF/ GSC) are mostly suggested.
Broad variety of RF Connectors OptionsSMA, SMB, SMC, MCX, MMCX, BNC, TNC, Micro coaxial connectors, to select the connector according to your applications, each series has different mating direction and termination style of socket and plug.
Different Locking System in RF SeriesThreaded mating option to ensure reliable and robust connection
Snap-on mating option ensures quick field installation
Bayonet coupling lock provides quick mating and un-mating solution
Size does Matter in Limited SpaceFrom the bigger series TNC/BNC/SMA to smaller series SMB/SMC/MMCX, the size effects the design just in order to fit the application when space limited.
Turnning Structure in ConnectorsIn order to provide a better signal transmission and EMI protection, connectors are constructed with full metal by turnning in stead of forming or stamping, the feature brings the excellent capability in high frequency field.
Coaxial Wire for Better TransmissionA typical Coaxial cable with double shield by braid and copper foil, and the solid wire as core, the structure is perfect to using for radio frequency application such as wireless or measurement equipment.
Hybrid Customized SolutionsExcept to assemble RF connector in both end, the hybrid customized cable is also feasible. RF cable use coaxial cale normally, but customer can take strand wire or tinned core wire instead, to make wire harness in particular condition. Moreover, micro coaxial plug to different RF connector end is also available.
