M Series

M12

SENSOR CONNECTOR M12 TYPE
  • M12

  • X
    (1)
  • R
    (2)
  •
    S
    (3)
  •
    04
    (4)
  • P
    (5)
  • D
    (6)
  • R
    (7)
  •
    WP
    (8)
  •
    H
    (9)

Description

  • (1) A,B.D,S,T,L,X: CODING POSITION
  • (2) R: RECEPTACLE
         P: PLUG
  • (3) S: SCREW THREAD MATING STYLE
  • (4) 04: NO. OF POSITION
  • (5) P: MALE
         S: FEMALE
  • (6) D: DIP STRAIGHT
         R: DIP RIGHT ANGLE
         A: SOLDER WIRE MOLDING TYPE
         S: SOLDER WIRE
  • (7) R: FRONT FASTEN(ENCLOSURE REAR MOUNT)
         F: REAR FASTEN(ENCLOSURE FRONT MOUNT)
  • (8) WP: WATERPROOF
  • (9) RoHS

DOWNLOAD

PART NUMBER SIZE FILE TYPE DRAWINGS
M12XRS-08SRR-WP-H 293KB PDF
download
DOWNLOAD
M16RS-08SA-H 334KB PDF
download
DOWNLOAD
M12XRS-08SDR-A-WP-H 271KB PDF
download
DOWNLOAD
M12DRS-04SDR-A-WP-H 262KB PDF
download
DOWNLOAD
M12DRS-04PDR-A-WP-H 254KB PDF
download
DOWNLOAD
M12DPS-04SS-WP-H 255KB PDF
download
DOWNLOAD
M12DPS-04PS-WP-H 256KB PDF
download
DOWNLOAD
M12BPS-04SS-WP-H 252KB PDF
download
DOWNLOAD
M12BPS-04PS-WP-H 265KB PDF
download
DOWNLOAD
M12ARS-XXSS-A-WP-H 255KB PDF
download
DOWNLOAD
M12ARS-08SDR-A-WP-H 266KB PDF
download
DOWNLOAD
M12APS-08PS-WP-H 266KB PDF
download
DOWNLOAD
M12APS-05PS-WP-H 255KB PDF
download
DOWNLOAD
