RCA JACK CONNECTOR

RCA

3.2 RCA JACK
  • RCA-J
  • R
    (1)
  •
    2X01
    (2)
  •
    BK
    (3)
  •
    H
    (4)

Description

  • (1)  D:DIP STRAIGHT
          DE:DIP STRAIGHT WITH TOP MOUNTING EAR
          R:DIP RIGHT ANGLE
          RE:DIP RIGHT ANGLE WITH TOP MOUNTING EAR
          RM:DIP RIGHT ANGLE METAL SHELL
          RR:DIP RIGHT ANGLE WITH RIGHT MOUNTING EAR
          RS:DIP RIGHT ANGLE WITH SWITCH
  • (2) BLANK:ONE PORT
         1X02,1X03,1X04,2X01,2X02,2X03,3X01,3X02,3X03:NO. OF PORT
  • (3) BK:BLACK INSULATOR
         RD:RED INSULATOR
         WH:WHITE INSULATOR
         YL:YELLOW INSULATOR
  • (4) H: RoHS

DOWNLOAD

PART NUMBER SIZE FILE TYPE DRAWINGS
RCA-JD-XX-H 232KB PDF
download
DOWNLOAD
RCA-JDE-1X02-XX-H 243KB PDF
download
DOWNLOAD
RCA-JR-XX-H 242KB PDF
download
DOWNLOAD
RCA-JRS-XX-H 254KB PDF
download
DOWNLOAD
RCA-JRM-XX-H 271KB PDF
download
DOWNLOAD
RCA-JRE-1X02B-XX-H 271KB PDF
download
DOWNLOAD
RCA-JRR-2X01-XX-H 276KB PDF
download
DOWNLOAD
