USB Type C

USB3

USB TYPE C SMT 90°/180°, DIP+SMT TYPE
  • USB3
    (1)
  •
    24
    (2)
  •
    C
    (3)
  •
    S
    (4)
  •
    W
    (5)
  •
    H
    (6)

Description

  • (1) USB3:USB TYPE C SERIES
    (2)  14:14 PIN
  •       16:16 PIN
  •       20:20 PIN(BOX TYPE)
          24:24 PIN
  • (3) C:TYPE C
  • (4) S:RECEPTACLE
          P:PLUG
  • (5) D:DIP STRAIGHT
          R:DIP RIGHT ANGLE
          S:SOLDER WIRE/MOLDING TYPE
          U:DIP UPRIGHT TYPE
          U-B:DIP UPRIGHT TYPE CH=7.2mm

    UW:SMT UPRIGHT TYPE
          V:SMT STRAIGHT
          W:SMT RIGHT ANGLE
          Y: DIP & SMT RIGHT ANGLE
  • (6) RoHS

DOWNLOAD

PART NUMBER SIZE FILE TYPE DRAWINGS
USB3-16CSW-R8H-H 415KB PDF
download
DOWNLOAD
USB3-16CSUWC-R5H-H 326KB PDF
download
DOWNLOAD
USB3-14CSU-B-SXX-HH 377KB PDF
download
DOWNLOAD
USB3-24CSW-PXX-R9H-H 165KB PDF
download
DOWNLOAD
USB3-24CPVPC-R4H-H 206KB PDF
download
DOWNLOAD
USB3-24CPE-15-SXX-H 318KB PDF
download
DOWNLOAD
USB3-24CPE-17-SXX-H 362KB PDF
download
DOWNLOAD
USB3-24CSVC-4-SXX-R3H-H 348KB PDF
download
DOWNLOAD
