DC Jack / Power Jack Connectors

DCP

DC PLUG
  • DCP

  • A
    (1)
  • 20
    (2)
  • 52
    (3)
  •
    95

  •
    H
    (4)

Description

  • (1)  A:ASSEMBLY TYPE
          BLANK:MOLDING TYPE
  • (2) 07:0.7mm PIN DIAMETER
          10:1.0mm PIN DIAMETER
          13:1.3mm PIN DIAMETER
          17:1.7mm PIN DIAMETER
          20:2.0mm PIN DIAMETER
          25:2.5mm PIN DIAMETER
          30:3.0mm PIN DIAMETER
  • (3) 19:1.9 OD DIAMETER
          23:2.3 OD DIAMETER
          35:3.5 OD DIAMETER
          36:3.6 OD DIAMETER
          47:4.7 OD DIAMETER
          50:5.0 OD DIAMETER
          52:5.2 OD DIAMETER
          55:5.5 OD DIAMETER
  • (4) RoHS

DOWNLOAD

PART NUMBER SIZE FILE TYPE DRAWINGS
DCP1335-H 264KB PDF
download
DOWNLOAD
DCP2050-H 156KB PDF
download
DOWNLOAD
DCP1135-H 241KB PDF
download
DOWNLOAD
DCP2555-H 74KB PDF
download
DOWNLOAD
DCPA2050-H 81KB PDF
download
DOWNLOAD
DCPA1135-H 164KB PDF
download
DOWNLOAD
