Housing,Header and Terminal

FH

1.25mm BOARD TO WIRE / WIRE TO WIRE
  • FH

  • 15
    (1)
  • H
    (2)
  •
    H
    (3)

Description

  • (1) 02~15:NO. OF POSITION
          T:FEMALE TERMINAL TIN PLATED
          M:MALE TERMINAL TIN PLATED
  • (2) H:FEMALE HOUSING
          P:MALE HOUSING
          D:MALE DIP STRAIGHT
          R:MALE DIP RIGHT ANGLE
          V:MALE SMT STRAIGHT
          W:MALE SMT RIGHT ANGLE
  • (3) RoHS

DOWNLOAD

PART NUMBER SIZE FILE TYPE DRAWINGS
FHT-R10K-H 80KB PDF
download
DOWNLOAD
FHXXH-H 255KB PDF
download
DOWNLOAD
FHXXW-R1K-H 282KB PDF
download
DOWNLOAD
FHXXVC-R1K-H 280KB PDF
download
DOWNLOAD
FHXXR-HH 266KB PDF
download
DOWNLOAD
FHXXD-HH 266KB PDF
download
DOWNLOAD
